NAK 16x24x5mm Corrugated Nitrile Rubber Single Lip Rotary Shaft Oil Seal with Garter Spring SG - Allow 7-10 Days

NAK SG Nitrile Oil Seals: Oil seals are used in a variety of different applications in which a rotating shaft is lubricated by oil or grease. They are engineered to facilitate the smooth operation of your equipment, serving as a barrier to prevent the leakage of oils and greases while also keeping foreign substances from entering. SG type seals have a special design of corrugated nitrile rubber on the outside diameter. These types are particularly suitable for applications where the housing material is subject to large thermal expansion, i.e. aluminium housings. The SG type features a single-sealing nitrile rubber lip on the inside diameter. The SG types feature a garter spring which allows some give to prevent a build-up of friction. (Seals under 5mm width may not always feature a spring.)
Benefits: Excellent wear resistance, good running properties, high resistance to chemicals and petroleum-based fuels including petrol, diesel and LPG.

Brand / Quality:

NAK - High Quality

Inside Diameter:

16mm

Outside Diameter:

24mm

Width:

5mm

Seals / Shields:

Nitrile

Style:

SG

Colour:

Black
