53204 Budget Single Thrust Ball Bearing with Spherical Housing Seat U204 20x40x17mm
53204 Budget Single Thrust Ball Bearing with Spherical Housing Seat U204 20x40x17mm
Regular price
$25.07
ex VAT
Regular price
Sale price
$25.07
ex VAT
In stock
Price Break
10+
$22.31
19+
$21.06
29+
$20.81
39+
$20.56
49+
$20.31
74+
$20.06
99+
$18.80
199+
$18.55
249+
$18.30
499+
$18.05
999+
$17.55
Couldn't load pickup availability
Description
Description
|
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 20mm
- Outside Diameter:
- 40mm
- Width:
- 17mm
Technical
Technical
| d | 20mm |
|---|---|
| D | 40mm |
| H1 | 17mm |
| Dynamic load C | 22.5 kN |
| Static load Co | 40.5 kN |
| Fatigue load limit Pu | 1.53 kN |
| Minimum load factor A | 0.0085 |
| Reference speed | 6000 rpm |
| Limiting Speed | 8000 rpm |
| Weight | 0.1 kg |
| Seating Washer | U204 |
| d1 | 40mm |
| D1 | 22mm |
| D2 | 30mm |
| D3 | 42mm |
| H | 14.73mm |
| C | 5mm |
| R | 36mm |
| s | 18mm |
| r1r2 min | 0.6mm |
| da max | 32mm |
| Da max | 30mm |
| ra max | 0.6mm |
