SKU: ESF211-SNR
SNR ESF211 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 55mm Bore - Allow 2-3 Days
SNR ESF211 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 55mm Bore - Allow 2-3 Days
Regular price
$71.62
ex VAT
Regular price
Sale price
$71.62
ex VAT
In stock
Price Break
10+
$63.74
19+
$60.16
29+
$59.44
39+
$58.73
49+
$58.01
74+
$57.30
99+
$53.72
199+
$53.00
249+
$52.28
499+
$51.57
999+
$50.13
Couldn't load pickup availability
Description
Description
ESF200 Series 4 Bolt Cast Iron Square Flange Housing: These cast iron housing units include a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: High tolerance to harsh environments, cost-effective bearing/housing assembly, re-lubricatable, replaceable insert, grub screw fixing
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 55mm
- Style:
- ESF
- Bolt Hole Centres:
- 130mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 55mm |
| A | 43mm |
| A1 | 18mm |
| A2 | 61.4mm |
| B | 32.5mm |
| B1 | 48.4mm |
| d1 | 74.5mm |
| e | 25mm |
| J | 130mm |
| L | 162mm |
| N | 19mm |
| S | 12mm |
| G | M6x1 |
| --- | Load rating |
| Dynamic load C | 43.55 kN |
| Static load C0 | 29.2 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 22 Nm |
| Mass | 3.06 kg |
