SKU: MFC2R-RHP
RHP MFC2R Four Bolt Round Cast Iron Flanged Bearing Unit and 2 inch Insert
RHP MFC2R Four Bolt Round Cast Iron Flanged Bearing Unit and 2 inch Insert
Regular price
$162.27
ex VAT
Regular price
Sale price
$162.27
ex VAT
In stock
Price Break
10+
$144.42
19+
$136.31
29+
$134.68
39+
$133.06
49+
$131.44
74+
$129.82
99+
$121.70
199+
$120.08
249+
$118.46
499+
$116.83
999+
$113.59
Couldn't load pickup availability
Description
Description
|
RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- MFC
- Pitch Circle Diameter:
- 130.18mm = 5.125 (5-1/8) inch
Technical
Technical
| Bore | 2 inch |
|---|---|
| L | 6.126 inch |
| H | 4.25 inch |
| J | 5.125 inch |
| G | 0.4375 inch |
| A1 | 1.562 inch |
| A4 | 0.748 inch |
| A5 | 0.252 inch |
| B | 2.031 inch |
| s | 0.752 inch |
| d1 | 2.449 inch |
| Dynamic load | 35000 N |
| Static load | 23200 N |
| Rec max speed | 3400 rpm |
| Weight | 2.7 kg |
| Insert | <a href="advanced_search_result.php?keywords=1050-2G+insonly">1050-2G Click Here</a> |
| Casting group | 4 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
