SKU: MSF1.3/4-RHP
RHP MSF1-3/4 Imperial Four Bolt Square Cast Iron Flange Housing and 1-3/4 inch Bore Grub Screw Insert
RHP MSF1-3/4 Imperial Four Bolt Square Cast Iron Flange Housing and 1-3/4 inch Bore Grub Screw Insert
Regular price
$141.11
ex VAT
Regular price
Sale price
$141.11
ex VAT
In stock
Price Break
10+
$125.59
19+
$118.53
29+
$117.12
39+
$115.71
49+
$114.30
74+
$112.89
99+
$105.83
199+
$104.42
249+
$103.01
499+
$101.60
999+
$98.78
Couldn't load pickup availability
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 44.45mm = 1.75 (1-3/4) inch
- Style:
- MSF
- Bolt Hole Centres:
- 110.998mm = 4.37 inch
Technical
Technical
| Bore | 1-3/4 inch |
|---|---|
| L | 5.626 inch |
| H | 4.563 inch |
| J | 4.37 inch |
| G | 0.625 inch |
| A | 1.563 inch |
| A1 | 2.383 inch |
| A4 | 0.563 inch |
| B | 2.031 inch |
| s | 0.752 inch |
| d1 | 2.449 inch |
| Dynamic load cr | 35000 N |
| Static load Cor | 23200 N |
| Rec max speed | 3400 rpm |
| Weight | 2.8 kg |
| Insert | <a href="advanced_search_result.php?keywords=1050-1-3/4G+insonly">1050-1-3/4G Click Here</a> |
| Casting group | 5 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
