SKU: SAL60TXE-2LS-SKF
SKF SAL60TXE2LS Left Hand Steel / PTFE Fabric Lined Plain Male Rod End M60x4 Thread
SKF SAL60TXE2LS Left Hand Steel / PTFE Fabric Lined Plain Male Rod End M60x4 Thread
Regular price
$802.54
ex VAT
Regular price
Sale price
$802.54
ex VAT
In stock
Price Break
10+
$714.26
19+
$674.13
29+
$666.11
39+
$658.08
49+
$650.06
74+
$642.03
99+
$601.91
199+
$593.88
249+
$585.85
499+
$577.83
999+
$561.78
Couldn't load pickup availability
Description
Description
- Brand / Quality:
- SKF - High Quality
- Thread Size:
- M60x4
- Thread M / F:
- Male
- Thread Direction:
- Left Hand
- Inside Diameter:
- 60mm
- Material:
- PTFE Fabric Lined
Technical
Technical
| d | 60mm |
|---|---|
| d2 max | 137mm |
| G | M60x4 |
| B | 44mm |
| C1 max | 39mm |
| h | 225mm |
| a | 6deg |
| Dynamic load C | 695 kN |
| Static load Co | 360 kN |
| Weight | 6.25 kg |
| dk | 80mm |
| l1 min | 120mm |
| l2 max | 296mm |
| l7 min | 73mm |
| r1 min | 1mm |
