SKU: SRBB15/2_15/30-TRAN
SRBB15/2 15/30 Tooth Metric En8 Steel Pair of Black Oxide Finish Bevel Gears 2:1 Ratio 1.5 MOD 20deg Pressure Angle
SRBB15/2 15/30 Tooth Metric En8 Steel Pair of Black Oxide Finish Bevel Gears 2:1 Ratio 1.5 MOD 20deg Pressure Angle
Regular price
$86.22
ex VAT
Regular price
Sale price
$86.22
ex VAT
Equivalent to: SRBB15/2
In stock
Price Break
10+
$76.74
19+
$72.42
29+
$71.56
39+
$70.70
49+
$69.84
74+
$68.98
99+
$64.67
199+
$63.80
249+
$62.94
499+
$62.08
999+
$60.35
Couldn't load pickup availability
Description
Description
Equivalent: SRBB15/2
- Brand / Quality:
- Drive-Flex - High Quality
- Bore:
- G1: 6mm / G2: 8mm
- Number of Teeth:
- 15/30
- Pitch Circle Diameter:
- G1: 26.11mm / G2: 45.88mm
Technical
Technical
| Gear 1 - Pitch Module | 1.5 |
|---|---|
| Gear 1 - No. Teeth | 15 |
| Gear 1 - dp | 22.5mm |
| Gear 1 - A+V | 32mm |
| Gear 1 - dm | 16mm |
| Gear 1 - Bore | 6mm |
| Gear 1 - F | 8mm |
| Gear 1 - A | 17.23mm |
| Gear 1 - de | 26.11mm |
| Gear 1 - S | 1.73mm |
| Gear 1 - Lm | 7.88mm |
| Gear 2 - Pitch Module | 1.5 |
| Gear 2 - No. Teeth | 30 |
| Gear 2 - dp | 45mm |
| Gear 2 - A+V | 25mm |
| Gear 2 - dm | 25mm |
| Gear 2 - Bore | 8mm |
| Gear 2 - F | 8mm |
| Gear 2 - A | 17.85mm |
| Gear 2 - de | 45.88mm |
| Gear 2 - S | 2.85mm |
| Gear 2 - Lm | 9mm |
