SKU: TBS-S-16B-45-DF
Drive-Flex 45 Tooth 16B Simplex Sprocket Tapered Locking Bush Type for 1 inch Pitch Chain Bush not Incl.
Drive-Flex 45 Tooth 16B Simplex Sprocket Tapered Locking Bush Type for 1 inch Pitch Chain Bush not Incl.
Regular price
$238.00
ex VAT
Regular price
Sale price
$238.00
ex VAT
In stock
Price Break
10+
$211.82
19+
$199.92
29+
$197.54
39+
$195.16
49+
$192.78
74+
$190.40
99+
$178.50
199+
$176.12
249+
$173.74
499+
$171.36
999+
$166.60
Couldn't load pickup availability
Description
Description
Tapered Bore Sprockets: Small sprockets are usually manufactured from C45 Steel and the large sprockets maybe supplied in G22 Cast Iron. These taper bore sprockets accept tapered locking bushes in a wide variety of shaft sizes to allow the end user to easily fit the sprocket to the shaft with minimal effort and no machining.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
- Brand / Quality:
- Drive-Flex - High Quality
- Number of Teeth:
- 45
- Pitch:
- 25.4mm = 1 inch
- Item Type:
- BS European Standard
Technical
Technical
| Tooth Radius r3 | 26mm |
|---|---|
| Chamfer c | 2.5mm |
| Tooth Width b1 | 15.8mm |
| Tooth Width B1 | 16.2mm |
| Tooth Width B2 | 47.7mm |
| Tooth Width B3 | 79.6mm |
| Pitch | 25.4mm |
| Width Between Inner | 17.02mm |
| Roller Diameter | 15.88mm |
| No. of Teeth | 45 |
| Outer Diameter de | 377.1mm |
| Pitch Diameter dp | 360.13mm |
| Hub Diameter dm | 140mm |
| Length Through Bore A | 51mm |
| Reference | 81-45 |
| Taper Bush | <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=3020+tapered+locking+bush>3020 Click Here</a> |
