SKU: UCP.211-34
UCP211-34 Imperial Cast Iron Two Bolt Pillow / Plummer Block Housing with 2-1/8 inch Bore Insert
UCP211-34 Imperial Cast Iron Two Bolt Pillow / Plummer Block Housing with 2-1/8 inch Bore Insert
Regular price
$53.55
ex VAT
Regular price
Sale price
$53.55
ex VAT
In stock
Price Break
10+
$47.66
19+
$44.98
29+
$44.45
39+
$43.91
49+
$43.38
74+
$42.84
99+
$40.16
199+
$39.63
249+
$39.09
499+
$38.56
999+
$37.49
Couldn't load pickup availability
Description
Description
|
UCP or NP Series Plummer / Pillow Housings: Supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required. Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 53.98mm = 2.125 (2-1/8) inch
- Style:
- UCP
- Bolt Hole Centres:
- 171mm
Technical
Technical
| d | 2-1/8 inch |
|---|---|
| h | 63.5mm |
| a | 219mm |
| e | 171mm |
| b | 60mm |
| s2 | 25mm |
| s1 | 20mm |
| g | 22mm |
| w | 126mm |
| B1 | 55.6mm |
| n | 22.2mm |
| Bolt Size | M16 |
| Weight | 3.4 kg |
| Dynamic load | 3400 kgf |
| Static load | 2550 kgf |
