SKU: WLT30-00-500-DURB
Durbal WLT30-00-500 Steel Spherical Plain Bearing with Cage 30x70x37mm
Durbal WLT30-00-500 Steel Spherical Plain Bearing with Cage 30x70x37mm
Regular price
$757.78
ex VAT
Regular price
Sale price
$757.78
ex VAT
In stock
Price Break
2+
$719.89
5+
$682.00
10+
$644.11
15+
$606.22
20+
$591.07
30+
$575.91
50+
$500.13
Couldn't load pickup availability
Description
Description
DURBAL Heavy-Duty Caged Spherical Bearings with Integral Self-Aligning Roller Bearing: These spherical bearings are made from hardened and super finished steel. For high speeds, wide swivelling angles or rotating movements. Suitable for high loads. Low maintenance due to long-term lubrication with food-grade approval. Covering discs on both sides to prevent the penetration of coarse dirt particles inside the bearing. Temperature range: -45 deg C to +120 deg C.
- Brand / Quality:
- Durbal - High Quality
- Inside Diameter:
- 30mm
Technical
Technical
| d | 30mm |
|---|---|
| D | 70mm |
| B | 37mm |
| C | 25mm |
| d1 | 34.5mm |
| tilt angle α | 7.5 deg |
| weight | 0.6kg |
| rotational speed limit n max | 450 min-1 |
| basic load rating dyn C | 32.5 kN |
| basic load rating stat Co | 24.9 kN |
| radial clearance CN | 10-30 µm |
