SKU: WLT40-00-500-DURB
Durbal WLT40-00-500 Steel Spherical Plain Bearing with Cage 40x120x66mm
Durbal WLT40-00-500 Steel Spherical Plain Bearing with Cage 40x120x66mm
Regular price
$1,631.07
ex VAT
Regular price
Sale price
$1,631.07
ex VAT
In stock
Price Break
2+
$1,549.52
5+
$1,467.96
10+
$1,386.41
15+
$1,304.86
20+
$1,272.23
30+
$1,239.61
50+
$1,076.51
Couldn't load pickup availability
Description
Description
DURBAL Heavy-Duty Caged Spherical Bearings with Integral Self-Aligning Roller Bearing: These spherical bearings are made from hardened and super finished steel. For high speeds, wide swivelling angles or rotating movements. Suitable for high loads. Low maintenance due to long-term lubrication with food-grade approval. Covering discs on both sides to prevent the penetration of coarse dirt particles inside the bearing. Temperature range: -45 deg C to +120 deg C.
- Brand / Quality:
- Durbal - High Quality
- Inside Diameter:
- 40mm
Technical
Technical
| d | 40mm |
|---|---|
| D | 120mm |
| B | 66mm |
| C | 49mm |
| d1 | 60mm |
| tilt angle α | 7 deg |
| weight | 3.05kg |
| rotational speed limit n max | 360 min-1 |
| basic load rating dyn C | 104.9 kN |
| basic load rating stat Co | 79.2 kN |
| radial clearance CN | 10-30 µm |
